Product Details:
Payment & Shipping Terms:
|
| Condition: | Used | Video Outgoing-inspection: | Provided |
|---|---|---|---|
| Machinery Test Report: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Vulcanizing Press | Machine Type: | Plate Vulcanizing Press |
| Warranty: | 1 Year | Key Selling Points: | Easy To Operate |
| Showroom Location: | None | Applicable Industries: | Manufacturing Plant, Machinery Repair Shops, Retail, Energy & Mining |
| Raw Material: | Aluminum Alloy | Application: | Water Cooling |
| Cooling System: | Water Cooling | Structure: | Horizontal |
| Heating Material: | Heater | Control Box Size: | 450x350x250 |
| Jointing Length: | 830mm | Vulcanizing Temperature: | 145℃ |
| Belt Width: | 1200mm | Weight: | 910KG |
| Marketing Type: | New Product 2020 | After Warranty Service: | Online Support |
| Local Service Location: | None | Port: | Ningbo/Shanghai |
width of vulcanized belt--max | mm | 1200 |
vulcanizing pressure | MPA | 1.0-1.8 Mpa(adjustable) |
vulcanizing temperature | ℃ | 145(adjustable) |
surface temperature of vulcanizing plate | ℃ | 145+/-5 |
heating-up time (from normal temperature to vulcanizing temperature) | min | 30 |
net weight | KG | 900 |
Adjustable temperature range | ℃ | 0-----200 |
Adjustable time range | min | 0---60 |
Voltage | V | 380/50 |
Overall sizes after assembled (LxWxH) | mm | 1970×830×725 |
Power of control box | kw | 19.1 |
Effective vulcanizing length | mm | 830 |
Dimension of heating plate(LxW) | mm | 1350×830 |
