Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Video Outgoing-inspection: | Provided |
|---|---|---|---|
| Machinery Test Report: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | PLC, Pressure Vessel, Pump | Machine Type: | Plate Vulcanizing Press |
| Voltage: | 380/50V | Dimension(L*W*H): | 1970mm X 830mm X 725mm |
| Weight: | 900KG, 910KG | Warranty: | 1 Year |
| Power (kW): | 19.1 | Key Selling Points: | Easy To Operate |
| Showroom Location: | None | Applicable Industries: | Manufacturing Plant, Construction Works , Energy & Mining |
| Raw Material: | Aluminum Alloy | Application: | Conveyor Belt Hot Vulcanizing Joint |
| Cooling System: | Water Cooling | Structure: | Horizontal |
| Heating Material: | Heater | Control Box Size: | 450x350x250 |
| Jointing Length: | 830mm | Vulcanizing Temperature: | 145℃ |
| Belt Width: | 1200mm | Marketing Type: | Hot Product 2019 |
| After-sales Service Provided: | Online Support, Video Technical Support | After Warranty Service: | Video Technical Support, Online Support |
| Local Service Location: | None | Port: | Ningbo/Shanghai |
| width of vulcanized belt--max | mm | 1200 |
| vulcanizing pressure | MPA | 1.0-1.8 Mpa(adjustable) |
| vulcanizing temperature | ℃ | 145(adjustable) |
| surface temperature of vulcanizing plate | ℃ | 145+/-5 |
| heating-up time (from normal temperature to vulcanizing temperature) | min | 30 |
| net weight | KG | 900 |
| Adjustable temperature range | ℃ | 0-----200 |
| Adjustable time range | min | 0---60 |
| Voltage | V | 380/50 |
| Overall sizes after assembled (LxWxH) | mm | 1970×830×725 |
| Power of control box | kw | 19.1 |
| Effective vulcanizing length | mm | 830 |
| Dimension of heating plate(LxW) | mm | 1350×830 |
