Product Details:
Payment & Shipping Terms:
|
| Applicable Industries: | Food & Beverage Factory, Restaurant, Food Shop, Food & Beverage Shops | Showroom Location: | None |
|---|---|---|---|
| Condition: | New | Material: | Pvc, PVC |
| Structure: | PVC Conveyor Belt | Power: | None |
| Warranty: | 1 Year | Width Or Diameter: | 200mm-3200mm |
| Machinery Test Report: | Provided | Video Outgoing-inspection: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Pvc Conveyor Belt | Weight (KG): | 100 Kg |
| Product Name: | PVC Conveyor Belt | Color: | Black,Green,White,Blue |
| Quality: | High Quality | Packing: | PP Waterproof Cloth |
| Thickness: | 1mm-10mm/customized | Size: | Customized Size |
| Length: | Customizable | Application: | Goods Transport |
| Standard: | ISO9001 | Port: | Ningbo/Shanghai |
Product name | Color | Working temperature | weight (KG/㎡) | Tensile strength | Pulling force required to extend 1% | Smallest roller Diameter (mm) | Hardness | Structure |
1.0 Flat | Green/White | -10/+80 | 1.1 | ≥50 | ≥4 | 20 | 75/65 | 1 cloth and 1 glue |
1.5 Flat | Green | -10/+80 | 2 | ≥50 | ≥5 | 30 | 75 | 2 cloth and 2 glue |
2.0 Flat | Green/White/Black | -10/+80 | 2.5 | ≥100 | ≥8 | 40 | 75 | 2 cloth and 2 glue |
3.0 Flat | Green/White/Black | -10/+80 | 3.8 | ≥100 | ≥8 | 60 | 75/65 | 2 cloth and 2 glue |
4.0 Flat | Green/White | -10/+80 | 4.5 | ≥100 | ≥8 | 60 | 75 | 2 cloth and 2 glue |
4.0 Flat | Green/White | -10/+80 | 4.8 | ≥150 | ≥12 | 80 | 75/65 | 3 cloth and 3 glue |
5.0 Flat | Green/White/Black | -10/+80 | 6.1 | ≥200 | ≥16 | 120 | 75 | 3 cloth and 3 glue |
6.0 Flat | Green | -10/+80 | 7 | ≥200 | ≥16 | 150 | 80 | 4 cloth and 4 glue |
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
1) 2--3 days for sample
2) 20--30 days for mass production. If urgent,we have green channel.
Low MOQ, 1pc for sample checking is available
Yes. Please inform us your logo or design before mass production
We are one of the top suppliers of International famous Belt company over years. Excellent quality is well accepted.
Please contact us for more details.
