Product Details:
Payment & Shipping Terms:
|
| Warranty: | 1 Year | Applicable Industries: | Manufacturing Plant, Construction Works , Energy & Mining |
|---|---|---|---|
| Weight (KG): | 4 | Showroom Location: | None |
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | New Product 2020 | Material: | Stainless Steel |
| Color: | Sliver | Surface Treatment: | Brushedor Customer's Requiment |
| Packing: | Box Packing+carton+pallets | Application: | Connection |
| Size: | 140E,190E,1.5", 2",2.5" | Delivery Time: | 3-10 Days |
| Sample: | Avaliable | MOQ: | 200 Pcs |
| Standard: | ISO Metric |
| Fastener Size | Belt Thickness Range | For Belts with Mechanical Fastener Ratings Up To: | Minimum Pulley Diameter | |||
| inch | mm | PIW | KN/m | inch | mm | |
| 1" | 3/16 ---- 7/16 | 5 --- 11 | 150 | 30 | 12 | 300 |
| 140E | 3/16 ---- 7/16 | 5 --- 11 | 225 | 40 | 14 | 360 |
| 190E | 5/16 ---- 9/16 | 8 --- 14 | 375 | 65 | 18 | 460 |
1.5" | 7/16 ---- 11/16 | 11 --- 17 | 300 | 50 | 18 | 460 |
| 2" | 9/16 ---- 13/16 | 14 --- 21 | 440 | 75 | 30 | 760 |
| 2.5" | 3/4 ---- 1 | 19 --- 25 | 450 | 75 | 42 | 1070 |
